Enphase QD Cable 60-72 Cells Cell Modules (1.7m).

QD Cable for 60-72 Cell Modules (1.7m Spacing, IQ8 Compatible).

The QD Cable (4x12AWG) is designed for 60-72 cell modules and is compatible with IQ8 Commercial Microinverters. It features connector spacing of 1.7m (5.6ft) and a maximum spacing of 1.3m (4.3ft) between microinverters. The 4-pin male connectors plug directly into the microinverters, with the connector count varying based on the cut length and must be in multiples of 3. A center tap is positioned every 6 connectors, with the first center tap occurring after 3 or 6 connectors. The cut will start at connector 1 or 4.

Note:

• Must be sold in multiples of 3 connectors.
• Cut cable lengths may include 2 sections with a minimum of 12 micro connectors on the shorter length.
• Field wireable connectors and/or a junction box may be required to follow design guidelines.

Key Features:

• Reliable
• Easy Installation
• Field Wireable QD Connectors
