Philadelphia Nexus 580W N-Type Bifacial Solar Module
Solar Modules

Philadelphia Nexus 580W N-Type Bifacial Solar Module

SKUMNB144(HCBF)-580W
MOQ1 Container
LocationNew Jersey (NJ)
Quantity Available2,886 Units
$156.60/W
Request for Quote Request for Shipping
Shipping Support Across the Contiguous U.S.
Backed by Manufacturer Warranty
Shipping Timing Confirmed With Quote

Philadelphia Solar 450W 108 N-Type Cells Bifacial Solar Panel Detail Image 1

Philadelphia Nexus 580W Bifacial 144 Cells

The Philadelphia Solar PS-MNB144(HCBF)-580W is a high-efficiency bifacial solar module designed for demanding solar energy applications.

Mechanical Specifications

CharacteristicsValue
Cells per Module144 (72 x 2)
Cell TypeN Type Mono-Crystalline
Front Surface3.2mm Tempered AR Coated Glass
Back CoverTransparent Backsheet
FrameAnodized Aluminum (Black/Silver
Junction BoxIP 68 With Original MC4
Cable Length1200mm Cable length could be customized
Fire ClassificationType 1
Module Dimensions (in)89.69 × 44.65 × 1.38
Module Weight (LB)63.93 ± 2.20 lbs
Modules per Pallet31
40 Feet High-Cube Container620

View the official product data sheet for detailed specifications and technical information. You can download it from the PDF viewer if needed.

View Data Sheet

View the manufacturer installation document in a new window. You can download it from the PDF viewer if needed.

No installation document is available for this product.

View the product warranty document in a new window. You can download it from the PDF viewer if needed.

No warranty document is available for this product.
